Description
-
Headstock
- Spindle Nose D1-6
- Spindle Bore 2 – 1/16”
- Taper of Spindle Bore No.6 MT
- Range of Spindle Speed 12 Changes. 32-2000r/min.
-
Feeds and Threads
- Max. Travel of Compound Rest 4 – 3/4″
- Max. Travel of Cross Slide 9”
- Leadscrew Pitch 4 T.P.I.
- Longitudinal Feeds Range 40 Kinds 0.0012” – 0.0252”/rev
- Cross Feeds Range 1/2 Longitudinal Feeds
- Metric Threads Range 53 Kinds 0.4 – 14 mm
- Inch Threads Range 40 Kinds 2-56 T.P.I.
- Diametral Pitches Range 32 Kinds 4-32 D.P.
- Module Pitches Range 44 Kinds SO.4 – 7 M.P.
-
Tailstock
- Diameter of Tailstock Sleeve 2 – 1/8”
- Travel of Tailstock Sleeve 4 – 3/4″
- Morsetaper of Tailstock Sleeve #4 MT.
- Cross Adjustment ±1/2”
-
Motor
- Power of Main Motor 7.5 HP 3Ph
- Power of Coolant Pump 1/8 HP 3Ph
- Dimension and Weight
- Overall Dimension 85”x41”x53”
- Packing Size 89”x44”x67”
- Gross Weight 4,400 lbs
STANDARD ACCESSORIES:
- Three Jaw Chuck and Taper
- Four Jaw Chuck and Adaptor
- Face Plate
- Steady Rest
- Follow Rest
- Chip Guard
- Thread Chasing Dial
- MT6/4 Sleeve and MT4 Centre
- Oil Gun
- One Set of Wrenches
- Operation Manual
COMPLETE WITH:
- Quick Change Tool Post
- Taper Turning Attachment
- Coolant System
