Description
FEATURES CONTINUE:
- Easily adjustable blade gap adjustment system from single point
- Fast and powerful back gauge with 1000 mm distance, moving by ballscrewed shafts, with automatic swing away feature
- Automatically pressure adjusted and powerful hold downs with maximum performance
- Cutting length adjustment allowing stroke adjustment for shorter sheets and shorten the cutting time
- Roller bearings on the table to help place sheets on the machine easily
- Two (2) 40” front support arms with flip stop & tilting stop
- Foot pedal available for single or continuous cutting
- Cutting line illumination
- One (1) 5’ Squaring Arm with scale & T-slot & tilting stop
SPECIFICATIONS:
- Cutting length: 3100 mm – 10’
- Cutting capacity (45 kg/mm²):MS 6 mm – 1/4”
- Cutting capacity (70 kg/mm²):SS 4 mm – 5/32”
- Throat depth: 50mm – 1.96”
- Stroke per minute: Min 1/min: 15
- Optional Hi Speed stroke per minute: Min 1/min 24
- Cutting angle: 1.30°
- Number of hold downs: 16
- Pressure: 14 ton
- Main motor: 15 kw – 20HP
- Backgauge motor: 0.75 kw
- Oil capacity: 200 Lt. .
- Backgauge travel: 1000 mm
- Backgauge speed: 120 mm/sec
- Number of sheet support arms: 2
- Table length: 3515mm /138”
- Table width: 500 mm – 20”
- Table height: 865 mm – 34”
- Width: 2200 mm – 86”
- Total width: 3700 mm -145.6”
- Length: 4110mm – 161”
- Height: 2200 mm – 86”
- Weight: 16,830 lbs.
- Warranty: 1year parts and labour
- Training: Included
