CIDAN SM-F 1013 Powered Shear

call for prices

The Cidan mechanical shear model HSM-F is designed in a strong, all-welded construction. The shear is driven by a sturdy direct drive gear motor with overload relay.

TECHNICAL INFORMATION:

  • Working Length : 122″
  • Drive power : 3HP
  • Speed : 35 cuts per minute
  • Weight : 3860 lbs.

Capacity:

  • 13 gauge mild steel
  • 18 gauge stainless steel
  • 125 aluminum
Category: Tag:

Description

STANDARD EQUIPMENT:
  • Sturdy, low-noise gear motor
  • Single or continuous stroke
  • Double sided blades
  • Motorized back gauge with manual fine adjustment (29.53″)
  • Finger protection
  • Sheet support with return plate
  • Cutting line light
  • Table extension: Can be extended to 31.5″ from the cutting line for better sheet handling
  • Safety guard with mechanical fencing
  • Squaring arm without T-groove for tilting stop (25.6″)
